Automating iSCSI Multipathing with Ansible

Multipathing (MPIO - Multipath I/O) is essential for high availability and performance in iSCSI storage environments. It allows multiple network paths between an initiator (client) and a target (storage), ensuring failover and load balancing. In this guide, we will set up iSCSI multipathing on Linux using Ansible, automating installation, configuration, and monitoring.

1. Why Use Multipathing?

Multipathing provides:

• Redundancy - If one network path fails, another takes over
• Load Balancing - Distributes I/O across multiple paths
• Higher Bandwidth - Uses multiple network interfaces to increase throughput
• Failover Support - Automatically switches paths when a failure occurs

We will use Ansible to automate the deployment of iSCSI and multipath tools on multiple nodes.

2. Ansible Role: iscsi_multipath

We will create an Ansible role called iscsi_multipath that:

• Installs required packages
• Configures iscsid.conf and multipath.conf
• Discovers iSCSI targets
• Logs in to multiple iSCSI paths
• Ensures multipathing is enabled and running

2.1. Role Directory Structure

iscsi_multipath/
├── tasks/
│   ├── main.yml
├── templates/
│   ├── iscsid.conf.j2
│   ├── multipath.conf.j2
├── vars/
│   ├── main.yml
├── defaults/
│   ├── main.yml
├── meta/
│   ├── main.yml
├── README.md

3. Ansible Role Configuration

3.1. Define Variables

Create defaults/main.yml:

iscsi_target_ips:
  - "192.168.2.253"
  - "192.168.3.253"

iscsi_target_name: "iqn.2025-03.com.example:storage"
iscsi_chap_username: "your_username"
iscsi_chap_password: "your_secure_password"

3.2. Install Required Packages

Create tasks/main.yml:

---
- name: Install iSCSI and multipath packages
  ansible.builtin.apt:
    name:
      - open-iscsi
      - multipath-tools
    state: present
    update_cache: true

- name: Deploy iSCSI configuration
  ansible.builtin.template:
    src: iscsid.conf.j2
    dest: /etc/iscsi/iscsid.conf
    owner: root
    group: root
    mode: '0644'

- name: Deploy Multipath configuration
  ansible.builtin.template:
    src: multipath.conf.j2
    dest: /etc/multipath.conf
    owner: root
    group: root
    mode: '0644'

- name: Enable and start multipathd
  ansible.builtin.systemd:
    name: multipathd
    state: started
    enabled: true

- name: Discover iSCSI targets
  ansible.builtin.shell: "iscsiadm -m discovery -t st -p {{ item }}"
  loop: "{{ iscsi_target_ips }}"
  register: iscsi_discovery
  changed_when: false

- name: Log in to iSCSI targets
  ansible.builtin.shell: "iscsiadm -m node -T {{ iscsi_target_name }} -p {{ item }} --login"
  loop: "{{ iscsi_target_ips }}"

- name: Ensure iSCSI login persists across reboots
  ansible.builtin.shell: "iscsiadm -m node -T {{ iscsi_target_name }} -p {{ item }} --op=update --name=node.startup --value=automatic"
  loop: "{{ iscsi_target_ips }}"

3.3. Templates for Configuration Files

templates/iscsid.conf.j2

iscsid.startup = /bin/systemctl start iscsid.socket

node.startup = automatic
node.leading_login = No

node.session.auth.authmethod = CHAP
node.session.auth.username = {{ iscsi_chap_username }}
node.session.auth.password = {{ iscsi_chap_password }}

node.session.scan = auto

templates/multipath.conf.j2

defaults {
    user_friendly_names yes
}

blacklist {
    devnode "^sd[a-z]"
}

multipaths {
    multipath {
        wwid "{{ iscsi_wwid }}"
        alias mpatha
        path_grouping_policy "multibus"
        path_selector "round-robin 0"
        failback immediate
        rr_weight priorities
        no_path_retry 5
    }
}

Note: The WWID (World Wide Identifier) should be retrieved manually using:

sudo multipath -ll

Then add it to vars/main.yml.

4. Running the Ansible Playbook

Create a playbook setup_iscsi_multipath.yml:

- name: Setup iSCSI Multipathing
  hosts: all
  become: true
  roles:
    - iscsi_multipath

Run the playbook:

ansible-playbook -i inventory setup_iscsi_multipath.yml

5. Verifying the Setup

Check Active iSCSI Sessions:

sudo iscsiadm -m session

Expected output:

tcp: [1] 192.168.2.253:3260,1 iqn.2025-03.com.example:storage
tcp: [2] 192.168.3.253:3260,1 iqn.2025-03.com.example:storage

Check Multipath Devices:

sudo multipath -ll

Expected output:

mpatha (3600140547f55689de4b49c098d9b1a3c) dm-0 LIO-ORG  ,iscsi_target
size=20G features='0' hwhandler='0' wp=rw
|-+- policy='round-robin 0' prio=50 status=active
| - 2:0:0:0 sdb 8:16 active ready running
|-+- policy='round-robin 0' prio=50 status=enabled
| - 2:0:1:0 sdc 8:32 active ready running

6. Conclusion

With this Ansible role, we have successfully:

• Automated iSCSI multipathing setup
• Configured persistent iSCSI sessions
• Ensured failover and load balancing
• Simplified deployment across multiple nodes

This setup ensures high availability and performance while eliminating manual configuration errors.
